High Pressure Heavy Duty Slurry Pump 150ZJ-A60

High-Pressure Heavy Duty Slurry Pump Model: 150ZJ-A60

ZJ series slurry pumps, totally designed and developed by Chinese local engineers. High-Pressure Heavy Duty Slurry Pumps are high head slurry pumps mainly used for filter press, coal washing, power plants, etc.. 150ZJ is a 6-inch discharge size slurry pump, with impellers varying from 420mm to 710mm.

Its wet-end spare parts are made of high chrome alloy ONLY, a kind of high abrasion and erosion-resistant white iron, similar to ASTM A532. There are no elastomer alternatives.

Material Construction:

Part Description Standard Alternative
Impeller A05 A33, A49
Volute Liner A05 A33, A49
Front Liner A05 A33, A49
Back Liner A05 A33, A49
Split Outter Casings Grey Iron Ductile Iron
Shaft Carbon Steel SS304, SS316
Shaft Sleeve SS304 SS316, Ceramic, Tungstan Carbide
Shaft Seal Expeller Seal Gland Packing, Mechanical Seal
Bearings ZWZ, HRB SKF, Timken, NSK etc.

Applications of High-Pressure Heavy Duty Slurry Pump 150ZJ-A60:

Filter Press Loading, Power Plants, Mineral Processing, Flue Gas Desulphurization, Coal Washing, Metallurgy etc.


Flowrate: 135-550m3/hr; Head: 14.7-63.5m; Speed: 490-980rpm; Lubircation: Oil

Impeller: 5-Vane Closed Type with max. passage size 48mm
